Pumping Unit Use Artificial Pump Sucker Rod Pump

Pumping Unit Artificial Use Sucker Rod Pump Description

Pumping unit is an artificial pump system used to connect the downhole pump assembly with the surface components that facilitate a pumping motion. This pump system uses different types of components that generate reciprocating motions which make it easy to lift fluids from bottom to the surface in a vertical movement. It is powered by a motor that causes the plunger to work in two strokes, i.e., up and down. The main components of a Pumping unit are a walking beam, power shaft, cranks, counter weighs, horsehead, polished rod, Pitman arms and Samson beams.

The downhole Sucker Rod Pump is used on onshore sites to create a mechanical lifting motion. This motion is created by a series of valves, plungers, rod strings and rods that are assembled together as a pumping system. A Sucker Rod Pump works in the following way:

• A motor and gear box runs the power shaft.
• Counter weights are added to the cranks at the end and the cranks lift the counter weights.
• The Pitman arms connect the walking beam with the cranks. The beam then hinges and lowers the plunger. When the plunger and the horse head are lowered, it completes 1 downstroke.
• When the horsehead and plunger are lifted up, the fluid gets lifted from the bottom to the surface. This completes the upstroke.
• The fluid flow determines the opening and closing of the valves. The standing valve is opened while the riding valve is closed during the upstroke. During the downstroke, the standing valve gets closed and the riding valve is opened.

Technical parameter list:

Features

1. Used in artificial lifting opertation

2. Stationary barrel, not travelling
3. Used on onshore oil production

Puyang Zhongshi Group Co., Ltd., restructured from SINOPEC in 1997 has 20 years experience on manufacturing petroleum machinery products . The company registered capital is 10 million U.S. dollars, with annual export 30 million U.S. Dollars.

We have competitive price of our main products like: subsurface sucker rod pump, pumping unit, cementing tools, wellhead (Christmas Tree), etc, with certificates of API11AX,API11E,API6A,API5CT,ISO14001 and ISO9001 approved. We have 9 factories, 580 employees, including more than 160 technicians and engineers.

With 20 years manufacturing experience and more than 10 years exporting experience, our main clients include all oilfields in China such as: Zhongyuan, Daqing, Shengli, Changqing, Nanyang, Karamay, etc and we have exported to more than 30 countries abroad such as: Indonesia, Thailand, Myanmar, Russia, Kazakhstan, Venezuela, Peru, Columbia, Canada, America, Sudan, Egypt, Iran, Australia etc.

We would like to cooperate with friends from all over the world with high quality products and service to achieve mutual development .
