    Hot Rolled Seamless Casing Pipe For Oil Well Drilling Round Section Shape

    Ask Lasest Price
    Brand Name : Zhongshi
    Model Number : 4 1/2"-20"
    Certification : API 5CT, ISO, QHSE
    Price : Negotiable
    Payment Terms : T/T, L/C
    • Product Details
    • Company Profile

    Hot Rolled Seamless Casing Pipe For Oil Well Drilling Round Section Shape

    Hot Rolled Seamless Alloy Steel Casing Pipe For Oil Well Drilling


    Casing pipe description:

    Casing seamless pipe is mainly used for supporting the wall of the well during and after the drilling to

    ensure the drilling process and the normal operation of the entire well after completion. The oil casing

    pipe is the lifeline for maintaining the operation of the oil well.



    Features:

    1. Length range R3
    2. API 5CT seamless pipe


    Technical specification:

    StandardAPI 5CT/ ISO11960
    GradeGroup.1

    H40/PSL.1, J55/PSL.1, J55/PSL.2, J55/PSL.3, K55/PSL.1, K55/PSL.2, K55/PSL.3,

    N80(1)/PSL.1, N80(1)/PSL.2, N80(Q)/PSL.1, N80(Q)/PSL.2, N80(Q)/PSL.3

    Group.2M65/PSL.1, M65/PSL.3, L80/PSL.2, L80(1)/PSL.1, L80(1)/PSL.3, L80(9Cr)/PSL.1, L80(13Cr)/PSL.1, C90/PSL.1, C90/PSL.2, C90/PSL.3, T95/PSL.1, T95/PSL.2T95/PSL.3
    Group.3P110/PSL.1, P110/PSL.2, P110/PSL.3,
    Group.4Q125/PSL.1, Q125/PSL.2, Q125/PSL.3,
    Minimum Order QuantityNegotiable
    Outside DiameterCasing4 1/2 inch to 20 inch or 114.3mm to 508mm
    Wall ThicknessAccording to API 5CT Standard
    LengthCasingR1 (4.88m to 7.62m), R2 (7.62m to 10.36m), R3 (10.36m to 14.63m)
    Processing typeSeamless
    Type of End-FinishCasingP, S, B, L

    Mechanical properties:


    StandardSteel gradeTensil Strength(Mpa)Yeild Strength(Mpa)Elongation(%)
    API 5CTJ55≥517379~5520.5%
    API 5CTK55≥655379~5520.5%
    API 5CTN80≥689552~7580.5%
    API 5CTL80≥655552~6550.5%
    API 5CTP110≥862758~9650.6%
