Polished Oilfield Sucker Rods Stable Performance Environmental Protection

Sucker Rods Alloy Steel Polished Rod 1 1/8 " x 30Ft AISI 4140 Pony Rod API 11B AISI 4130

Product Description:

Sucker rod is manufactured according to API Spec 11B which mainly includes grade D and K. Grade H sucker rod is developed to suit for deep well and pcp pumps. Zhongshi alway provide the sucker rods which have the D ,K, KD , HL, HY type sucker rod.

Sucker Rod Features:

1. Grade C sucker rod: Moderate strength, not susceptible to sulfide stress cracking, suitable in sour medium.
2. Grade D sucker rod: Made of quality heat treated steel alloy, with high tensile and yield strength; suitable for non-corroding or mildly corroding environment.
3. Grade K, KD sucker rod: With good corrosion resistance in H2S, CO2 and NaCl media, superior tensile strength.
4. Grade HL and HY sucker rod: High strength; structure and size matching with grade D sucker rod; withstanding 966-1, 136 MPa (140, 000-164, 720 psi); suitable for deep and large displacement wells

5. Grade D 1 inch Oilfield hollow sucker rod for well drilling oil gas producing

Sucker Rod Specification:

Size in (mm)	Rod Body diameter in (mm)	diameter of ext. thread in (mm)	Full size Coupling OD mm (in)	Coupling OD mm (in)	Wrench square W*L mm (in)	Length series m (ft)
5/8 (16)	5/8 (15.88)	15/16 (23.81)	38.10(1.5)	31.8 (1.25)	22.2×31.8 (7/8×1-1/4)	7.62 (25)
3/4 (19)	3/4 (19.05)	1-1/16(26.99)	41.28(1.625)	38.1 (1.5)	25.4×31.8 (1×1-1/4)	9.14 (30)
7/8 (22)	7/8 (22.23)	1-3/16 (30.16)	46.0(1.812)	41.3 (1.625)	25.4×31.8 (1×1-1/4)	0.6 (2), 1 (3)
1 (25)	1 (25.40)	1-3/8 (34.93)	55.6(2.187)	50.8 (2)	33.3×38.1(1-5/16×1-1/2)	2 (6), 3 (10)
1-1/8 (28)	1-1/8 (28.58)	1-9/16 (39.7)	60.33(2.375)	57.2 (2.25)	38.1×41.3 (1-1/2×1-5/8)

Mechanical Properties of Sucker Rods:

Grade	Min Yield strength 0.2% offset M Pa (psi)	Tensile strength M Pa (psi)	Elongation δ%	Reduction of area ψ%
K	414 (60, 000)	621-793(90, 000-115, 000)	≥13	≥60
C	414 (60, 000)	621-793(90, 000-115, 000)	≥13	≥50
D	586 (84, 970)	793-965 (114, 985-139, 925)	≥10	≥50
KD	590(85, 000)	793-965 (114, 985-139, 925)	≥10	≥50
HL	795(115,000)	965-1,195(140,000-173,339)	≥10	≥45
HY	540 (78, 300)	965-1,195(140,000-173,339)	≥42	≥224
