RH Series RW Series And TH Series Inserted Rod Pump

Ask Lasest Price
Brand Name :	Zhongshi
Model Number :	RHAC
Certification :	API, ISO, QHSE
Price :	Negotiable
Payment Terms :	L/C, D/P, T/T, Western Union, D/A
Supply Ability :	1000 SETS/MONTH
Delivery Time :	10~15 workdays

Add to Cart

Product Details
Company Profile

RH Series RW Series And TH Series Inserted Rod Pump

Rod type and tubing type inserted rod pump description

Our sucker rod pumps are categorized according to the API 11AX pump designation.
API-RHAC, Rod, Stationary Heavy Wall Barrel, Cup Top Anchor Pump
API-RHBM, Rod, Stationary Heavy Wall Barrel, Mechanical Bottom Anchor Pump
API-RHBC, Rod, Stationary Heavy Wall Barrel, Cup Bottom Anchor Pump
API-RWAM, Rod, Stationary Thin Wall Barrel, Mechanical Top Anchor Pump
API-RWAC, Rod, Stationary Thin Wall Barrel, Cup Top Anchor Pump
API-RWBM, Rod, Stationary Thin Wall Barrel, Mechanical Bottom Anchor Pump

Our tubing pumps are categorized according to API 11AX designation

API-TH,Tubingl, Heavy Wall Barrel, Tubing Pump
Product Description:
API-TH(B)M,Tubing ,Heavy Wall Barrel ,Mechanical Anchor Pump
API-TH(B)C,Tubing ,Heavy Wall Barrel ,Cup Type Anchor Pump

Sucker rod pump and tubing pump models and specifications:

API models	Pump OD mm(in)	m(ft)Plunger Length	Stroke m	m3/d Pump Constant	Tubing And Thread	In Sucker Rod
20-125TH	32(1.25)	1.2-1.8 (4-6)	0.6-7.3	1.14	27/8NU/EU	¾
20-125RHAC/M	32(1.25)		0.6-7.3	1.14	27/8NU/EU	¾
20-125RHBC/M	32(1.25)		0.6-7.3	1.14	27/8NU/EU	¾
20-125RHTC/M	32(1.25)		0.6-7.3	1.14	27/8NU/EU	¾
25-125TH	32(1.25)		0.6-7.3	1.14	27/8NU/EU	¾
25-150RHAC/M	38(1.50)		0.6-7.3	1.64	27/8NU/EU	¾
25-150RHBC/M	38(1.50)		0.6-7.3	1.64	27/8NU/EU	¾
25-150RHTC/M	38(1.50)		0.6-7.3	1.64	27/8NU/EU	¾
20-150TH	38(1.50)		0.6-7.3	1.64	27/8NU/EU	¾
25-150TH	38(1.50)		0.6-7.3	1.64	27/8NU/EU	¾
20-175TH	44(1.75)		0.6-7.3	2.24	27/8NU/EU	¾
25-175RHAC/M	44(1.75)		0.6-7.3	2.24	27/8	¾
25-175RHBC/M	44(1.75)		0.6-7.3	2.24	27/8NU/EU	¾
25-175RHTC/M	44(1.75)		0.6-7.3	2.24	27/8NU/EU	¾
25-175TH	44(1.75)		0.6-7.3	2.24	27/8NU/EU	¾
25-225TH	57(2.25)		0.6-7.3	3.69	27/8NU/EU	¾
30-275TH	70(2.75)		0.6-7.3	5.50	3½NU/EU	7/8
30-225RHAC/M	57(2.25)		0.6-7.3	3.69	3½ NU/EU	¾
30-225RHBC/M	57(2.25)		0.6-7.3	3.69	3½ NU/EU	¾
30-225RHTC/M	57(2.25)		0.6-7.3	3.69	3½ NU/EU	¾
35-325TH	83(3.25)		0.6-7.3	7.70	4NU/EU	7/8
40-375TH	95(3.75)		0.6-7.3	10.26	4½NU/EU	1

Inserted pump Features: Simple structure and easy operation is main feature of rod pump.
